Touch Screen Open Frame LCD Display

Shenzhen TopAdkiosk Technology Co., Ltd is a professional manufacturer and supplier of Touch Screen Open Frame LCD Display products. Our LCD Displays use LG A+'s new original LCD screen, which is available in various sizes such as 32-inch, 43-inch, 49-inch and 55-inch. We support customized services to meet the individual needs of customers.

Send Inquiry

Product Description

TopAdkiosk's Touch Screen Open Frame LCD Display support multiple operating system options, including Windows 7 and Android 4.4. The touch screen uses 10-point capacitive touch screen or infrared touch screen technology to provide a smooth touch experience. In addition, in terms of network connection, Touch Screen Open Frame LCD Display support multiple options such as RJ45, 3G and WIFI to meet different network needs.

As a manufacturer and supplier located in China, we are committed to providing advanced technology and high-quality products. We provide competitive price lists and guarantee Touch Screen Open Frame LCD Display quality. Shenzhen TopAdkiosk Technology Co., Ltd provides customers with professional services to ensure customer satisfaction.

Detailed Product Description

Type:	TFT	Max Resolution:	1920*1080
Viewing Angle:	178/178	Input Voltage:	AC100V-240V (50HZ-60HZ)
Brightness:	400 Cd/m*2	OS:	Window, Android
Touch Screen:	Infrared /Capacitive	I/O Port:	2XUSB 3.0, 1XRJ45, 1 XHDMI
Size:	22-86"
High Light:	wall mount lcd display, wall mounted kiosk

43inch open frame white color Industrial sensitive capacitive touch android windows touchscreen monitor
Available Sizes: 32" 43" 49" 55"

Feature:

LG A+ full new original LCD screen
OS:Windows 7 and Android 4.4 option
Touchscreen:10points capacitive touchscreen/Infrared touch screen
Network:RJ45, 3G, WIFI (optional)

Size	32inch	43inch	49inch	55inch	65inch
Screen Type	LED	LED	LED	LED	LED
Max Resolution	1920*1080	1920*1080	1920*1080	1920*1080	1920*1080
Brightness	360cd/m2	360cd/m2	360cd/m2	360cd/m2	360cd/m2
Aspect Ratio	16:9	16:9	16:9	16:9	16:9
Color	16.7M	16.7M	16.7M	16.7M	16.7M
Viewing Angle	178°	178°	178°	178°	178°
Response Time	8ms	8ms	8ms	8ms	8ms
Voltage Input	AC100~240	AC100~240	AC100~240	AC100~240	AC100~240
Power consumption	360W	460W	500W	620W	1000W
Standby consumption	2W	2W	2W	2W	2W
Speaker Output	10Watts	10Watts	10Watts	10Watts	10Watts
Speakers	2 x Internal Speakers
Frame Color	Bright Black and Bright Silver
Frame Material	Steel Construction
Screen Material	Tempered Glass
Security	Ports, Connectors and Controls are Located within a Lock-Protected Compartment
Working Environment	-20°C ~ +60°C
Working Humidity	10%-90%
Inputs	HDMI x 1, USB x 2, Component
Certifications	CE, ROHS, CCC. FCC, ISO9001
Accessories	Power Adapter, Wired Plug, User Manual and Installation Bracket
Product Warranty	1 Year Warranty

Android OS:
OS	Android 4. 4 OS
CPU	RK3288,1.8GHZ
DDR	2G DDR3
ROM:	8G NAND FLASH
Exteral ROM	Support up to 32G bytes sd card and support stata hard disk interface
WiFi	Support 802.11b/g/n wifi module
Interface	USB2.0,Ypbpr,VGA,AV,SD card slot,3G interface,SIM Card,RJ45

Windows OS(PC1 solution)
CPU	Intel Dual core J1900 Processor (2.8GHz, Quad Core)
Chipset	INTEL®GM45+ ICH9M-E
RAM	4GB DDR3 1333 RAM (Up to 6GB)
Graphics	INTEL® HD Video card
Audio	HD 8-channel (7.1) audio subsystem
Network	10/100/1000M Gigabit Ethernet Controller
WiFi	High quality WiFi module included (802.11 B/G/N)
H.D.D.	128 GB SSD
Speaker	2 build-in high quality stereo speakers (5w
O.D.D	DVD-RW (Optional)
Mouse/Keyboard	Bluetooth suit (Optional)
Pre-Installed OS	Windows7
TV Tuner	No

Windows OS(PC2 solution option):
CPU	Intel Core i3 (3th generation, Dual Core)/i5/i7
RAM	4GB DDR III 1333 RAM (Up to 16GB)
Graphics	INTEL® HD Video card
Audio	HD 8-channel (7.1) audio subsystem
Network	10/100/1000 Mbits/sec Ethernet LAN connectivity
WiFi	High quality WiFi module included (802.11 B/G/N)
H.D.D.	120GB SSD
Speaker	2 build-in high quality stereo speakers (3w or 5w)
O.D.D	DVD-RW (Optional)
Mouse/Keyboard	Bluetooth suit (Optional)
Pre-Installed OS	Windows 8 or Linux
TV Tuner	Optional

FAQ:

Q:How long is the warranty time for your products?
A: Our officially promised warranty time is one whole year after delivery at best.
Q: When will you make the delivery?
A: We can make the delivery within 3-15 working days or depend on the size and quantities of your order.
Q:what brand of screen are you using?
A:we are using Samsung,LG and AUO screen.
Q: Do you have your own enclosure factory?
A:Yes we do have our own enclosure factory,and we have the best structural Engineer,we hope to provide you with best screen and shape,so OEM is also welcome.
Q:Do you give any discount ?
A: We are Manufacturer, so we are able to give you the best price and best service at the same time.
Q:What payment methods your company accept?
A:We accept most of the payment methods,but mainly accept T/T, WesternUnion,Paypal and MoneyGram
